3 Way Sanitary Ball Valve with Tri-clamp Ends, Manual Type
3 Way Sanitary Mini Ball Valve

3 Way Sanitary Ball Valve with Tri-clamp Ends, Manual Type

SV-2MDC-3 series is a manual type sanitary 3-way ball valve with tri-clamp / tri-clamp ends, which is extensively used in food & beverage processing, brewing, oil refinery, cosmetic, pharmaceutical, and chemical industries to control medium flow. The full port design with zero restrictions makes it an optimum choice for viscous and particulate liquids, SV-2MDC-3 ball valve operates manually by 180° rotary handle.

Categories: ,

Additional information

Reference

SV-2MDC-3
Size

1/2" to 4" (DN10 – DN100)
End Connection

Butt-weld, Tri-clamp, Thread, Flange, I-line, KF, etc.
Body Material

AISI 304, AISI 304L, AISI 316, AISI 316L
Seat Material

TEFLON (PTFE)
Max. Working Pressure

145psi (10bar)
Working Temperature Range

-4°F to 356°F (-20℃ to 180°C)
Operation

Manual Handle
3-way Body Types

T-port or L-port, Flow Plan D/E/F/G/A
Surface Finish

Ra 16-32µin (0.4-0.8µm), Ra 32µin (0.8µm) as default.
