Additional information
| Reference | SV-13R |
|---|---|
| Size | 1/2" – 3" (DN10-DN65) |
| End Connection | butt-weld, tri-clamp, threaded, bolted |
| Body Material | AISI 304, AISI 316L |
| Head Type | sphere or elliptical |
| Sphere Sizes | 22mm, 28mm, 45mm, 65mm |
| Cleaning Radius | max. 13ft (4m) under 58psi (4bar) |
| Cleaning Angle | 360° spray, 270° spray, 180° spray |
| Flow Rate | max. 70GPM (16m³/h) |
| Working Temperature Range | 14°F ~ 248°F (-10°C ~ 120°C) |
| Surface Finish | Ra 16-32µin (0.4-0.8µm), Ra 32µin (0.8µm) as default. |
