Additional information
| Reference | SV-4MP |
|---|---|
| Size | 1" to 2 1/2" |
| End Connection | Tri-clamp, Butt-weld |
| Body Material | ASTM A351 CF3M (1.4435) as default, AISI 316L Forged Body (1.4435), ASME BPE 316L, or 1.4435-BN2 (316L) Fe＜0.5% Forged Body |
| Seat Material | EPDM+PTFE |
| Max. Working Pressure | 0-145PSI (10BAR) |
| Working Temperature Range | -22° F to 356 ° F (-30°C to 180°C ) |
| Operation | stainless pneumatic actuator, NC/NO/AA type for choose from |
| Surface Finish | Ra 16-32µin (0.4-0.8µm), Ra 32µin (0.8µm) as default. |
