Additional information
| Reference | SV-18HHQ |
|---|---|
| Solid Inlet Sizes | 3"-4" (DN80-DN100) |
| Liquid Inlet Sizes | 1 1/2"-2 1/2" (DN40-DN65) |
| Outlet Sizes | 2"-3" (DN50-DN80) |
| End Connection | Butt-welded, Tri-clamp, Threaded, Flanged |
| Body Material | AISI 316L |
| Mechanical Seal | Single Mechanical Seal |
| Max. capacity of powder | 9000kgs/H |
| Max. capacity of thickeners | 3000kgs/H |
| Working Temperature | -40°F to 302°F (-40°C to 150°C) |
| Surface Finish | Ra 16-32µin (0.4-0.8µm), Ra 32µin (0.8µm) as default. |
| Motor Power Range | 3KW-22KW |
| Voltage | AC110V, 220-240V, 360-400V, 420-460V, 630-690V, 50/60Hz |
